Parametry:
Chipset:
Intel B560
Patice:
Socket 1200
Rozměrový formát:
micro ATX
Podpora pro procesory:
11th Gen Intel® Core™ Processors & 10th Gen Intel® Core™, Pentium® Gold and Celeron®
Sloty na paměti:
4 x DDR4 DIMM Slots, podpora až 128 GB
Grafická karta:
ano
Zvuková karta:
Realtek ALC887/897
Síťová karta:
1 x Realtek 2.5Gb Ethernet
SATA:
6 x SATA 6Gb/s
BIOS:
128 Mb Flash ROM, UEFI AMI BIOS
Interní porty:
1 x 4-pin CPU Fan header(s)
1 x 4pin CPU OPT Fan header(s)
2 x 4-pin Chassis Fan header(s)
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
2 x M.2 slots (Key M)
6 x SATA 6Gb/s ports
1 x USB 3.2 Gen 1 konektor (support(s) USB Type-C®)
1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports
2 x AURA Addressable Gen 2 header(s)
2 x AURA RGB header(s)
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x 20-3 pin System Panel header with Chassis intrude function
1 x Thunderbolt™ header
Externí porty:
2 x USB 3.2 Gen 2 port(s) (2 x Type-A)
3 x USB 3.2 Gen 1 port(s) (2 x Type-A, 1 x USB Type-C®)
4 x USB 2.0 port(s) (4 x Type-A)
1 x DisplayPort
1 x HDMI port
1 x ASUS Wi-Fi Module
1 x Realtek 2.5Gb Ethernet port
5 x Audio jacks
1 x Optical S/PDIF out port
